Human Presence Sensor 24G Millimeter Wave Radar WiFi Communication

  • 1
  • 2
  • 3

Brand Name : Multi IR

Model Number : MIR-HE200-WF

Certification : CE,FCC,ROHS

Place of Origin : Shenzhen, China

MOQ : Standard packing 200pcs. OEM packing 2000pcs

Price : Negotiable

Payment Terms : T/T in advance

Supply Ability : 5000pcs/day

Delivery Time : 25 working days

Packaging Details : 80PCS/CTN, Carton size: 435*390*355mm

Product Name : Human Presence Sensor

Communication protocol : wifi

Transmission Frequency : 2.4GHz

Transmission Power : ≤19dBm

Communication Distance : 70m (open-air)

Working Voltage : AC 110V-220V

Contact Now

Tuya WiFi Radar Human Presence Detector Human Body Sensing Detection

1 Function description

[24G Millimeter Wave Radar ]The human presence sensor is based on a millimeter-wave Doppler radar system detects human movement and static status.

[Light sensor] The human presence detector is with a light sensor to detect the real time illumination. With a light sensor built-in, the detector can sense the light illumination in real-time, user can connect it with a dimmer to enjoy a comfortable life.

Suitable for home, hotel, office, etc.

2 Technical parameters

Communication protocol wifi
Transmission Frequency 2.4GHz
Transmission Power ≤19dBm
Communication Distance 70m (open-air)
Working Voltage AC 110V-220V
Detecting Distance Movement: 6*8m; Static: 4*8m; Sleeping: 3.6*2.2m
Detecting type Millimeter wave Doppler radar
Detecting Angle 90°
Detecting mode Un-occupy/Occupied, Movement/Static
Illuminance sensing Support(0-4500 illuminance)
OTA upgrade Support
Network button Support
Installation height 2.75m(vertical deviation angle≤5°)
Dimension Φ80x42mm

Human Presence Sensor 24G Millimeter Wave Radar WiFi Communication

Human Presence Sensor 24G Millimeter Wave Radar WiFi Communication

Human Presence Sensor 24G Millimeter Wave Radar WiFi Communication

Human Presence Sensor 24G Millimeter Wave Radar WiFi Communication

Human Presence Sensor 24G Millimeter Wave Radar WiFi Communication
